Heavy Duty 22.5×9.00 Off-Highway Tubeless Truck Wheel

22.5×9.00 TUBELESS

heavy-duty 22.5×9.00 rim with 16mm disc and 5500kg capacity

Share:

HEAVY DUTY TRUCK WHEEL/RIM/DISC:

PART NO.:22904901

Tubeless wheels for trucks, buses, semi-trailers, trailers.

Designed with a reinforced 16mm disc and 7mm rim thickness, this wheel ensures outstanding durability under extreme stress. The wide offset of 175mm enhances vehicle stability in off-road operations such as mining, quarrying, or construction.

APPLICABLE ROAD

OFF-HIGHWA
RIM SIZE

22.5×9.00
RIM THICKNESS

7
DISC THICKNESS

16
HAND HOLE TYPE

ROUND
HAND HOLE NO.

10
STUD HOLE NO.

10
STUD HOLE DIA.

φ26
STUD HOLE TYPE

ROUND
P. C.D

φ335
C.B.D

φ281
OFFSET

175
MAX LOAD

5500
WEIGHT (KG)

49
