Heavy Duty 22.5×8.25 Off-Highway Tubeless Wheel for Harsh Terrain

22.5×8.25 TUBELESS

tubeless truck rim for high-load transport vehicles

Share:

HEAVY DUTY TRUCK WHEEL/RIM/DISC:

PART NO.:22823701

Tubeless wheels for trucks, buses, semi-trailers, trailers.

This 22.5×8.25 Off-Highway tubeless wheel is designed to endure the toughest terrains in mining, construction, and other off-road applications. With a disc thickness of 12.5mm and rim thickness of 5.5mm, it provides enhanced structural strength for demanding loads.

The 3750kg maximum load capacity makes it ideal for heavy-duty earthmoving trucks and off-road haulers. A φ335 P.C.D and φ281 C.B.D ensure perfect compatibility with large commercial axles. The 165mm offset offers optimal vehicle balance and safety when maneuvering over uneven surfaces.

APPLICABLE ROAD

OFF-HIGHWA
RIM SIZE

22.5×8.25
RIM THICKNESS

5.5
DISC THICKNESS

12.5
HAND HOLE TYPE

ROUND
HAND HOLE NO.

10
STUD HOLE NO.

10
STUD HOLE DIA.

φ26
STUD HOLE TYPE

ROUND
P. C.D

φ335
C.B.D

φ281
OFFSET

165
MAX LOAD

3750
WEIGHT (KG)

37
