22.5 Rims for Sale | Heavy-Duty Truck Rims & 10 Lug Semi Wheels

22.5×9.00 TUBELESS

Tubeless commercial truck rim – 3750kg capacity

Share:

HEAVY DUTY TRUCK WHEEL/RIM/DISC:

PART NO.:22904601

Tubeless wheels for trucks, buses, semi-trailers, trailers

Heavy-duty 22.5x9.00 tubeless truck wheel with 13.5mm disc thickness, 4500kg max load, and 46kg net weight. Ideal for highway-use trucks and trailers requiring high strength with reduced rim weight.

APPLICABLE ROAD

ON-HIGHWAY
RIM SIZE

22.5×9.00
RIM THICKNESS

6.9
DISC THICKNESS

13.5
HAND HOLE TYPE

ROUND
HAND HOLE NO.

10
STUD HOLE NO.

10
STUD HOLE DIA.

φ26
STUD HOLE TYPE

ROUND
P. C.D

φ335
C.B.D

φ281
OFFSET

175
MAX LOAD

4500
WEIGHT (KG)

46
